Recording Feed from FOH Mix

Your Questions: Recording Feed from FOH Mix

Today’s question about the recording feed comes from Noel in Hudson, Florida.

“I need to see if you can help me with some of the audio settings for our streaming. We have the Behringer X32. We feed our video software out of a Matrix on the mixer. But we are having to compress it a lot so it doesn’t clip. It’s there a way to feed the software without having to compress it a lot. It just makes the mix sound like it is really dry. I would like it to sound powerful and loud enough. Any help will be greatly appreciated. Thank you so much.”

Recording Feed from the FOH Mix

This is very common in a lot of the churches I have visited in the past. The church is recording their sermon or recording the worship for a video feed directly off of the main mix that is coming from the ‘Front of House’ sound board. There is one important problem that we have to solve when the music and the sermon are recorded in the same stream.

The problem is that the music will record at a higher volume than any natural speech. Typically, music is performed around 95 dB and speech/sermons are normally around 70-75 dB. This accounts for a -20 dB difference on the recording between music and the sermon. In some venues, this difference can vary up to 30dB!

Recording Feed from FOH Mix

How to Overcome!

To eliminate the recorded volume issue, I set up a recording bus on Mixbus 11 and Mixbus 12 with a ‘Post Fader’ sends preconfiguration. Since this is a ‘Post Fader’ setup, any mix changes in the house mix would also happen in the recording feed.

Here is the main trick: All of the ‘music channels’ on the board (singers, drums, guitars, bass, FX Returns, etc.) are sent to the pair of busses at -10 dB. Any speech channels like Pastor, Pulpit or Announcement Mic should be sent to these busses at +5dB.

  • Music Channel: Set to -10 dB on Mixbus 11 & 12
  • Speech Channel: Set to +5 dB on Mixbus 11 & 12

Setting up the recording Mixbus this way will set full music volume and speech at close to the same volume in the recording.

Recording Feed from FOH Mix

As we can see above, Music and Speech would be reaching the recorded mix around the same level!

Post Fader Mixbus ‘Fine Tuning’

If we use a post-fader setup, our mix in the house will still translate to the recording, except that we have trimmed the volume down.

After the first week of use, go back and listen to the recording in your car or at home. Listen for any changes between the live service and the recording. One common issue is that the drums end up NOT loud enough in the recording. Since the drums are so loud live in the room, most don’t need to put much of the drums in the PA system. In turn, this forces the drums to record at a low level.

As you find these different adjustments that need to be made, make sure to write them down. Next time you are at the board, adjust the sends level of those channels up or down as needed going into Mixbus 11 & 12. Next week, repeat this process and by the 3rd Sunday, you should have the recording levels set perfectly!

Another great part of this recording feed being on the Mixbus is that it can be sent to a matrix if you need to have volume adjustment to match an external piece of gear, or have a volume control like a Lobby or Mother’s Lounge.

Compression

I suggest keeping the compression for that matrix on a ratio of 10:1, 20:1, or 100:1, as these settings will change the compressor to a limiter. You are going to have dynamics in the mix, like a snare drum, that will constantly clip a mix, the limiter will help keep those dynamics to a low for recording. Another option is to use the ‘Precision Limiter’ effect in your effects rack. You will need to tweak either the compressor or the limiter to have good audio quality, but keep the clipping to a minimum.

Equalization

Lastly, to really get your mix sounding like it did in the room during the live show, we want to add a bit of ‘equal-loudness contour’ adjustment to the EQ of Mixbus 11 & 12. If you haven’t heard of the ‘Fletcher-Munson Curve‘ or the ‘Equal-Loudness Contour‘, I would recommend reading up on them!

In a quick summary, our ears hear frequencies in different amounts depending on the volume of the source we are listening to. The quieter the source, the less sensitive our hearing is for high and low frequencies. These curves and contours put those findings into a graphical & numerical representation. I have extrapolated that data and was able to make a similar EQ curve using the mixbus EQ of the Behringer X32 so that we can boost and cut the frequencies so that when you listen to the recording at 80dB, it will ‘sound’ the same as if you were in the room at 100dB!

FREE Download!

CLICK HERE to download a Library file that you can load onto the mixbusses to give the ‘Equal-Loudness Contour’ a spot in your system!

How to Set This Up

Here are the steps to get this working!

  1. On the right fader bank, Press the button for Mixbus 9-16.
  2. Select Mixbus 11, then Press Home button to right of LCD screen.
  3. Press the first encoder knob to ‘Link’ Mixbus 11 & 12 together. Confirm popup.
  4. Tab over to ‘Config’ and then rotate the 3rd encoder knob to select ‘Post Fader’, Press the 3rd encoder knob to select Post Fader as the ‘Channel Sends Preconfiguration’. Confirm popup.
  5. With Mixbus 11 still selected, press ‘Sends on Fader’.
  6. On left fader bank, set any music related channels at -10 dB, and set any speech related channels at +5 dB. (Don’t forget to go through all the layers, Channels 1-32, Aux 1-6, FX Returns)
  7. Press ‘Sends on Fader’ to return X32 back to normal mixing mode.

That’s it! Hopefully, this will help you get your recording mix sounding great and similar to how it sounded during the service! Don’t forget to set your USB Recorder to pull from this mixbus for the stereo board recording!

Connect with me

Recent posts

21 Responses

  1. This never worked for us. As we were also live streaming our service, we went to a second X32 console (taking it’s feed from the sanctuary X32 console – AES50(B) out to AES50(A) in) in an isolated room with good quality monitor speakers.

    Works great.

  2. I assume that you are using Mixbus 11 & 12 for stereo … if I run a mono setup can I drop one of the Mixbuses?

  3. Do you really mean to have the service recordings at 0dBfs?
    I understand that it just may be an “example” number, but getting a signal at 0dBfs is guaranteed trouble if anything ever wants to be done with/to the recording.

  4. Thanks for the post!!! Will this set up work for the video feed for broadcasting? Routing the mix buses 11 and 12 to proper outputs.

    Thanks!!

  5. Thanks so much for this tutorial. Tried it out last night and it worked very well. Just wondering if you have any idea to blend a room mic in since it’s not in the main mix?

  6. Drew,

    Thanks as always for your thorough tutorials & blog!

    I’m not in front of the console atm so I can’t double check, but don’t you also need to ensure Bus 11/12 are de-selected from the Stereo/Mono Bus to avoid double busing to the mains? Or does that happen automatically when configuring it as a Post-Fader group?

    Also, it seems worth noting that if you use advanced routing with SubGroups for all inputs (including a spoken word bus separate from lead & ensemble vocal bus(es), this is only marginally easier to do via Matrices, but in the end it will save you from eating up 2 extra buses. Best!

  7. I have a potentially dumb question. I have gotten pretty good at the live mix, but cannot figure out how to route straight from the console to a Mac. I have been recording to a flash drive and then transferring to the computer. How do i go about routing straight to the Mac? We use Adobe Audition. Can you help me out of link me to an article? Thanks!

  8. Thanks Drew. With all of that, how do you set up and wire the MixBusses to the recording device?

  9. For this. Should you still use a matrix for the right and left and also have the bus go into the matrix? Or just have the bus only?

  10. This is super helpful!
    One thing I would like to do is have an ambient mic in the room to help the praise band hear the audience, as well as to give streaming video a more realistic feel. Is there a way to do this with this setup?

    I’m having difficulties since the bus is postfader, but we have the ambient mic all the way down since it wouldn’t make sense to have this in the house mix.

  11. Great article! I have a question regarding the post-fade mixbus setting. I have ambient mics that need to go to the livestream but not the house (pre-fade). How do I add them to a post fade bus?

  12. Do I still have to follow this guide if i’m only recording the music (no sermons or speaking)?

    So then I can just still use the Main out L + R to record to USB like I have been?

    Thanks,

  13. Hello Drew,
    I run sound for a church in Virginia and I am having a problem with the drums. I can not get the balance between to much signal for the main left right and having enough signal for the p-16s on stage. Any help would be greatly appreciated.

  14. If you have installed the X-Live Card you can use a recorded session to adjust the mixbus levels immediately without waiting from week to week. Once correctly adjusted between the different channels you should overcome the problematic speech/music problem or the fact that loud instruments (like drums) don’t need much attention in your FOH mix.

  15. Thanks for this post. I’m grateful. And one question: I can use a Equal-Loudness Contour in master or my PA too? Thaks for all
